Manitou MT625 6m Telehandler

Description

The MT 625 H telehandler is specially designed for building sites and renovation projects involving lower heights. Its compact dimensions - with a width of 1.8 m and under 2 m in height - mean you can easily pass under thresholds and navigate congested areas. Its 3.3 m turning radius and 3 steering modes available provide you with excellent maneuverability. Easy to use, this handler features an ergonomic instrument panel and JSM-equipped joystick to easily execute all machine funtions in one control. The MT 625 H has a lift capacity of 2.5 t, with a maximum lift height of 5.85 m. Its 75 hp engine reaches speeds of up to 25 km/h. Maintenance is made easy with the wide opening angle of the engine hood. The 90 l gear pump allows for simultaneous movement of the boom and telescope for increased productivity.

Technical Information

Length - 3.83m

Width - 1.81m

Height - 1.92n

Wheelbase - 2.30m

Ground Clearance - 0.33m

Overall Cab Width - 0.79m

Tilt Up Angle - 12 Degrees

Tilt Down Angle - 117 Degrees
