JLG Scissor lift - 8m
Product Images
Description
Self-propelled scissor lift with pendant control that allows all lift and drive functions to be carried out by operators whilst the unit is elevated.
Sturdy and ideal for narrow access.
MORE ECONOMIC - Electric power for zero emissions and near-silent running indoors.
MORE PRODUCTIVE - Boost efficiency with direct electric drive.
MORE ACCESS - Get into more places with compact dimensions and precise control system.
SMART DESIGN - Enjoy industry leading upcycles so you can work longer with higher productivity.
Technical Information
- Working Height 9.92 m
-
Platform Height – Elevated 7.92 m
A. Stowed Height 2.39 m
B. Platform Railing Height 1.10 m
C. Stowed Height (Rails Folded) 1 2.01 m
D. Platform Size (W x L) 1.12 m x 2.50 m
E. Deck Extension 1.27 m
F. Overall Width 1.17 m
G. Overall Length 2.50 m
H. Wheelbase 2.09 m
I. Ground Clearance 0.13 m - Platform Capacity 2 450 kg
- Capacity on Optional Deck Extension 120 kg
- Lift/Lower Time 40/50 sec.
- Maximum Drive Height 7.92 m
- Machine weight 2,740 kg
